Flatbed 5 Ton Truck Mounted Crane Dongfeng Hydraulic Telescopic Boom Crane

Product Categories

HUBEI HUAYI SPECIAL AUTOMOBILE CO.,LTD

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Flatbed 5 Ton Truck Mounted Crane Dongfeng Hydraulic Telescopic Boom Crane

MOQ : 1

Price : 15000-35000 per unit

Gearbox : Fast, 6forwards & 1reverse

Cargo Thickness : Side 1.5mm, Bottom 2.5mm

Specification : 7070*2335*3250 mm

Origin : Suizhou, China

Condition : New

Engine Brand : Chaochai, 120HP

Boom Type : Straight 4-Arm Telescopic Boom

Transport Package : Naked, Waxed, Bulk Ship, RO-RO

Place of Origin : CHINA

Brand Name : EHY

Maximum Lifting Height : 10-15m

Type : Straight Arm

Crane Boom Type : Straight Telescopic Crane, Knuckle Crane

Crane Brand : S-Any, Rlq, etc.

Trademark : EHY

Crane Capacity : 2ton, 3ton, 3.5ton, 4ton, 5ton, 2.5ton, etc.

Shaft Number : 2

Chassis Brand : Dongfeng, Sinotruk HOWO, Foton, FAW, JAC, Jmc, Isu

Production Capacity : 500 Unit/Month

Name : Truck Mounted Crane

Model Number : EHY

Payment Terms : 50% Deposit,Balance should be paid before ship out

Supply Ability : 10unit per month

Model NO. : EHY5089SCD

Crane Jib : Four-Arm

Maximum Lifting Weight : 2-4t

Cargo Material : Q235 Carbon Steel

HS Code : 8705909990

Contact Now

5 Tons Dongfeng Hydraulic Telescopic Boom Truck Mounted Crane Cargo Crane

Product Description

Purpose: It's used for lifting and transporting all kinds of bulk cargo, and also applied in jetty and construction work.

Main parts: Crane. (Different lifting capacities match different chassis.)

Advantage: One truck combines the functions of crane and dump truck.

Product Specification

Product name	dongfengTruck Mounted with Crane with 3.2T Capacity
Chassis modeldom	dongfeng Truck with Crane
OD(mm)L×W×H	Aprro 707023353250 mm
The size of the box	43502150550 mm
Total Mass	8250KG
Axle load	2090KG/4720KG
Color	According to your requirement
Engine
Maximum power	105KW
Displacement	3856ml
Fuel type	Diesel Oil
Wheel Base(mm)	3800
Type & Size of Tyre	7.00-16 14PR,7.00R16 14PR
Number of tyre	6
Max Speed	110Km/h
Technical parameter of crane(Straight Boom & Folding-Type Boom)
Crane weight (KG)	1200
max. lifting weight(KG)	4000
Rotation Angle	360º

Equipment for 4tons Crane Mounted Parts
Working Platform	360°turning(left or right), H-shape legs 360°
Cargo Box Dimension	4350×2150×550mm
Material of box body	Carbon steel
Extendable boom section	1
Boom Type	Straight
Lifting Max. Weight	4000KG
Lifting Max. Height	7560 mm
Working Radius	7730 mm

Flatbed 5 Ton Truck Mounted Crane Dongfeng Hydraulic Telescopic Boom Crane
