FOTON 4X2 Cement Concrete Mixer Truck 10m3 Loading Capacity

Product Categories

HUBEI HUAYI SPECIAL AUTOMOBILE CO.,LTD

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

FOTON 4X2 Cement Concrete Mixer Truck 10m3 Loading Capacity

Engine Capacity : 4200ml

Warranty : 1 Year

Loading capacity : 5 CBM

Place of Origin : CHINA

Brand Name : EHY

MOQ : 1

Model Number : EHY

Price : 15000-35000 per unit

Payment Terms : 50% Deposit,Balance should be paid before ship out

Supply Ability : 10unit per month

Video outgoing-inspection : Provided

Weight : 5800 kg

Machinery Test Report : Provided

Core Components : Engine, Gearbox, Motor, Pump

Power(W) : 130HP

Hydraulic motor : Italy PMP

Chassis brand : BJ4182GJB-G1

Make : Foton

Dimension(L*W*H) : 6460X2500X3650mm

Horse power : 130HP

Emissions standard : Euro 4

Hydraulic pump : Italy PMP

UNIQUE SELLING POINT : Fully hydraulic system

Engine model : YC4D130-41

Drive form : 4X2

Reducer : Italy PMP

Radiator : Kaipeng

Contact Now

PRODUCT SPECIFICATIONS

Vehicle Parameters
Vehicle Model	EHY5250GJBA	Vehicle Brand	EHY
Overall dimensions	8100X2500X3750mm	Curb weight	12300kg
Loading capacity	10m3	Color	optional
Chassis Parameters
Chassis model	DFL5250GJBA	Chassis brand	DONGFENG
Overall dimensions	8090x2500x3030mm	Wheel base	3800+1350mm
Cab	D310 Sleeper cab, forward control type, low roof, new face, all welded steel cab of tilt type, mechanical cab tilting, rear mechanical cab suspension , adjustable driver’s seat, air conditioning system
Engine	Dongfeng L375 30
	Horse power	375hp
	Emission	Euro 3
	Displacement	8900ml
Tire	315/80R22.5	Transmission	9JS150T-B DD 9 forward & 1 reverse
Steering device	Power assisted steering	Steering wheel	Left hand drive
Concrete Mixer Structure Parameters
Mixing capacity(m³)	10	Color and Logo	Optional
Feeding speed (m³/min)	≥5	Discharge speed(m³/min)	≥3
Discharge residual rate	≤0.5%	Slump scope(mm)	50-210
Water tank capacity(L)	300	Water pressure(Mpa)	0.35-0.38
Tank material	5mm alloy steel	Tank front head	8mm alloy steel
Standard Configuration	chassis, sub frame, mixer tank, reducer, hydraulic pump, hydraulic motor, radiator, water tank, cleaning hose, feed port, discharge port, climbing ladder, air pressure water supply device.

Working Overview

FOTON 4X2 Cement Concrete Mixer Truck 10m3 Loading Capacity

Recommend Products

Company Profile

Our Advantages

Product Test and Training for Customer

We will test each product before shipment, and also provide online or face to face operation training for customer

Design & Technical & Quality meeting each week

We will discuss with R&D about the questions and feedback from customer to ensure all the quality of products and after-sales service.

FAQ

1. What is your terms of payment?

T/T with 30% deposit, and 70% balance will be paid before delivery. We will show you photos of the products and packages before you paying the balance.

2. What's your MOQ?

1 set.

3. How about delivery time?

25 workdays after we received 30% of contract value T/T down payment. customized types depends on configuration and order quantity.

4. Do you have advantage on price?

We offer all the trucks with factory directly selling price.

5. How about the afer-sales service?

Our engineer will be ready to offer online-supporting for any technical questions for you.

Packing and Shipping
