Dongfeng Flatbed Wrecker Truck 3tons 4tons With 3ton Lifting Weight

Flatbed Dimensions : 7200*2450mm

Emission Standard : Euro 5

Length of Steel Cable : 25m

Rating Under-Pulling Capacity : 6000kg

Place of Origin : CHINA

Brand Name : EHY

Condition : New

Tire : Steel Tire

Winch Rating Pulling Capacity : 6000kg

Bearing Capacity : 6ton

Engine : 180HP

Trademark : EHY

Name : Flatbed Wrecker Truck

Max. Loading Weight : 6000kg

Specification : 3T, 3ton, 3tons 4t 4tons 4ton

Gearbox : 6 Forward & 1 Reverse

Origin : Suizhou, China

HS Code : 8705909990

Model Number : EHY

Payment Terms : 50% Deposit,Balance should be paid before ship out

Supply Ability : 10unit per month

Model NO. : EHY59206BGQ

MOQ : 1

Price : 15000-35000 per unit

Transmission Type : Manual

Brand : Dongfeng

Transport Package : Bulk, RO-RO, Container

Towing Tonnage : 6ton

Delivery Time : 30 Days

Production Capacity : 500unit Per Month

Fuel : Diesel

Contact Now

Flatbed Wrecker Truck with 3ton Lifting Weight

Product Description:

Purpose of 6ton flatbed tow truc: wrecker/recovery truck/towing truck is used for towing broken cars,vehicle on road.With increasing ownership of private cars,wreckers are now widly used by government organization or towing company.
Optional brand of 6ton flatbed tow truc:howo,Dongfeng,JAC,JMC,Foton,Shacman...
Spare parts of 6ton flatbed tow truc: Italy brand multi-way valve and balance valve; Gernamy Roxroth technology hydraulic cylinder and joint; imported sealing element; strengthed checked plate
Capacity range of 6ton flatbed tow truc:3ton, 4ton, 5ton, 6ton, 8ton, 12ton, 16ton, 20ton, 25ton, 31ton, 40ton, 50ton
The customers can choose to install the crane.

General Technical Parameters
Overall Dimension			9440x2480x2760 (mm)
Gross Vehicle Weight			12495kg
Curb Weight			8000kg
Chassis Specification
Chassis Parameters	Chassis Brand		Dongfeng
	Cabin		Row and half, Right Hand Driving
	Engine	Model	ISD180 50, 4 Cylinders
		Power	132KW/180HP
		Emission Standard	EURO V
		Displacement	4.5L
		Fuel Type	Diesel
	Gearbox		6 Forward & 1 Reverse Gear
	Front and Rear Axle Load		4.5T/9T
	Wheel Base		4700(mm)
	Overhang( Front/Rear)		1015/2450(mm)
	Angle(Approach/departure)		24/9(°)
	Brake System		Air Brake
	Steering Gear		Power Assistant
	Tire		9.00R20, 6 Pieces with 1 Spare Tire
	Maximum Speed		110(km/h)
Superstructure
Flatbed	Dimensions		7200x2450 (mm)
	Max. Loading Weight		6000(kg)
	Operating Stroke		3300 (mm)
	Min. Angle of Slope		8(°)
	Platform Height from the Ground		1070(mm)
Winch	Quantity		1pc
	Winch Rating Pulling Capacity		6000 (kg)
	Length of Steel Cable		25 (m)
Hoisting Organ	Rating Under-Pulling Capacity		6000 (kg)
	Rating Under-Hoisting Capacity		2000 (kg)
	Fully Extended Max Under-Hoisting Capacity		1600 (kg)
	Max Under-Hoist Useful Length		1640 (mm)
Remarks	1. Equiped with One Set of Auxiliary Wheels 2. Bandages 4pcs 3. Yellow Warning Lamp 1pc 4. Double Side Hydraulic Operation 5. Can Tow 2 Cars
